Memento in VB.NET
Capture and restore an object's internal state
ReturnWithout violating encapsulation, capture and externalize an object's internal state so that the object can be restored to this state later. Memento pattern temporary saves and restores another object's internal state.
Please download project with this source code from https://github.com/ViacheslavUKR/StandardDisignOopPattern
1: ' Memento Design Pattern.
2: ' See description in //www.vb-net.com/ProgramTheory/Memento.htm
3: Class MainApp
4: ' Entry point into console application.
5: Public Shared Sub Main()
6: Dim o As New Originator()
7: o.State = "On"
8: ' Store internal state
9: Dim c As New Caretaker()
10: c.Memento = o.CreateMemento()
11: ' Continue changing originator
12: o.State = "Off"
13: ' Restore saved state
14: o.SetMemento(c.Memento)
15: ' Wait for user
16: Console.ReadKey()
17: End Sub
18: End Class
19:
20: ' The 'Originator' class
21: Class Originator
22: Private _state As String
23: ' Property
24: Public Property State() As String
25: Get
26: Return _state
27: End Get
28: Set(value As String)
29: _state = value
30: Console.WriteLine(Convert.ToString("State = ") & _state)
31: End Set
32: End Property
33: ' Creates memento
34: Public Function CreateMemento() As Memento
35: Return (New Memento(_state))
36: End Function
37: ' Restores original state
38: Public Sub SetMemento(memento As Memento)
39: Console.WriteLine("Restoring state...")
40: State = memento.State
41: End Sub
42: End Class
43:
44: ' The 'Memento' class
45: Class Memento
46: Private _state As String
47: ' Constructor
48: Public Sub New(state As String)
49: Me._state = state
50: End Sub
51: ' Gets or sets state
52: Public ReadOnly Property State() As String
53: Get
54: Return _state
55: End Get
56: End Property
57: End Class
58:
59: ' The 'Caretaker' class
60: Class Caretaker
61: Private _memento As Memento
62: ' Gets or sets memento
63: Public Property Memento() As Memento
64: Get
65: Return _memento
66: End Get
67: Set(value As Memento)
68: _memento = value
69: End Set
70: End Property
71: End Class
